Tooth chip crusher
Tooth chip crusher
The company's main products are: automatic conveyor, bucket elevator, screw conveyor, belt conveyor, slat conveyor, FU drag chain conveyor, bucket conveyor, crusher and all kinds of manual, electric, pneumatic gate valves, slag silo and so on.
PRODUCT DESCRIPTION
The tooth chip crusher is suitable for crushing small lumps of materials that are prone to moisture absorption,caking,hardening,and have specific particle size requirements.It is particularly applicable to the light industry and paper-making industry,specifically for the crushing of alkali ash in the alkali recovery system of alkaline boilers and the crushing of sodium sulfate (mirabilite) under the mirabilite silo in the feeding system.
The tooth chip crusher features a set of stationary toothed plates arranged symmetrically on both sides with uniform spacing,and a set of rotating hammer blades symmetrically arranged in a spiral pattern on the high-speed rotating main shaft.During operation,the rotating hammer blades overlap and mesh with the stationary toothed plates. As the lumpy material in the upper chamber falls, it is crushed by the impact of the rotating hammer blades and the shearing action between the hammer blades and the toothed plates.The spacing between the stationary toothed plates,the spacing between the rotating hammer blades,and the clearance between them are determined based on the required particle size of the material.The shape of each rotating hammer blade is designed as a scissor-tooth pattern,with 2,3,4,5,6,7,or 8 teeth depending on the outer diameter,symmetrically and evenly distributed around the circumference.
This type of crusher can operate continuously and reliably,ensuring that materials not meeting the particle size requirements cannot fall into the lower chamber.Due to the scissor-tooth design of the rotating hammer blades,the material in the upper chamber cannot roll or slip,preventing blockages.In case of unexpected failures such as overload or motor stalling,the crusher is protected by both mechanical and electrical safety devices,which can promptly trigger alarms and shut down the machine.
This tooth chip crusher, use a group of left and right sides is symmetrical evenly spaced teeth patches of crushing plate, a set of evenly spaced into helical symmetry layout on the high-speed spindle dynamic tooth chip, work, move hammer with the tooth crushing plate into overlapping bite shape, cavity ofthe block materialfalling on passive hammer hammer of the impact and dynamic tooth slice and cut cut pieces of broken plate and broken. Using the interval distance between tooth slice of crushing plate,tooth hammer of distance and the gap between each other, decided by the control material particle size and the size of the requirements.Single chip design dynamic tooth hammer into dentate,scissors according to outer diametersize can be 2, 3, 4,tooth, 5, 6,tooth,tooth, 7, 8 symmetrical evenly distributed on the circumference of a circle. The breakage function is continuous and reliable work, do not conform to the requirements of the particle size of material can not fall into the inferior vena. For dynamic cylindrical gear hammer is scissors dentate, cavity material cannot roll slippage and plugging material. Overload occurs when the crusher, stuffy car accident such as failure, can be by mechanical and electrical.
●Dimensions of tooth chip crusher
●Technical parameters sheet of tooth chip crusher
(the parameter in the table is calculated according to the characteristic of the glauber'ssalt,soda ash.if it is hard material taking high-power)
|
Machine size |
Diameter of rotor mm |
Length of rotor mm |
Rotating speed of rotor r/min |
The max feed particle size mm |
discharging granularity mm |
Output |
Power of the motor kw |
|
CP3040 |
270 |
400 |
22～48 |
100 |
≤14 |
5 |
5.5 ,7.5,11 |
|
CP4040 |
370 |
400 |
22～48 |
150 |
≤14 |
8 |
7.5,11,18.5 |
|
CP4060 |
370 |
600 |
22～48 |
200 |
≤14 |
12 |
11,18.5,22,30 |
|
CP5060 |
470 |
600 |
22～48 |
200 |
≤14 |
18 |
18.5,22,30,37 |
