En masse conveyor (Buried Scraper Conveyors) : An In - Depth Look

Author :

Yiyun

En masse conveyor (Buried Scraper Conveyors) are remarkable pieces of equipment in the world of material handling. They are designed to continuously transport bulk materials like dust, small particles, and small pieces within a closed rectangular section shell. As the name implies, during operation, the scraper chain is completely buried in the material, hence “En masse conveyor (Buried Scraper Conveyors)”.

The working principle of these conveyors is fascinating. Materials possess internal friction and lateral pressure. When in horizontal transport, the scraper chain thrusts the materials, causing internal friction between material layers. When this internal friction overcomes the external friction between the material and the tank wall, a continuous material flow moves forward with the scraper chain. In vertical lifting, the material’s arching properties come into play. The pressure from the scraper chain and the pushing force from the continuously fed lower - level materials enable the material to be lifted.

Buried scraper conveyors offer numerous advantages. They have a simple structure and can be flexibly arranged for horizontal, inclined, or vertical transport. Their sealed shell effectively prevents environmental pollution, making them ideal for transporting toxic, explosive, or high - temperature materials. They also allow for multi - point feeding and discharging, which is highly convenient in various industrial processes.​
These conveyors find wide applications across industries such as metallurgy, building materials, power, chemicals, and food. They are reliable workhorses that contribute significantly to the efficient movement of materials in production lines.





en masse conveyor,buried scraper conveyor,material handling
